Brinell Hardness Testing Machine Specifications

E 10 standard test method for brinell hardness of metallic material.

Brinell hardness testing machine specifications.

The wilson bh3000 is a durable 30 kn 3000 kgf brinell hardness tester that is ideal for wide range of brinell loads from 62 5 kgf 3000 kgf. A brinell hardness result measures the permanent width of indentation produced by a carbide indenter applied to a test specimen at a given load for a given length of time. Semi automatic brinell hardness testing machine is designed for measuring the brinell hardness of steels other ferrous materials as well as non ferrous materials like brass bronze aluminium etc. Designed with rugged construction to withstand harsh environments the reliable bh3000 brinell hardness testing machine combines high rigidity and closed loop load cell technology to ensure accurate.

Relatively high loads are applied to parts via a tungsten carbide ball in this method. These machines are designed to measure hardness of casting forgings other metals and alloys of all kinds hard or soft whether flat round or irregular in shape. Brinell hardness machine equipment for brinell hard ness testing usually consists of a testing machine which supports the test specimen and applies an indenting force to a ball in contact with the specimen and a system for measuring the mean diameter of the. Test forces range from 500 to 3000 kgf.

Specifications for brass plate sheet strip and rolled bar. Unlike with rockwell testing brinell tests measure the diameter of the indentation made by the ball not the depth. A chart is then used to convert the averaged diameter measurement to a brinell hardness number. The machine is a combined version wherein rockwell hardness under a b and c scales and brinell tests can be conducted.

Brinell testing machines shall be verified periodically using test blocks. Practices for force verification of testing machines. The machine is supplied complete with ball and diamond indenters together with test block for hrb and hrc scales and ball indenter for brinell hardness test. This machine basically used in foundries forging units engineering industries material testing laboratories heat treatment plants.

E 110 indentation hardness of metallic material by portable. Experts in hardness testers and hardness test equipment including rockwell brinell and microhardness testers optical systems and software. Standard accessories testing table 200 mm 1 pc.
